Which Is The Best Chasis Cooling Fan Power Cable Hub Splitter Adapter

Features:

Excellent 1 to 5 splitter 5 way 4-pin PWM fan power supply extension cable cord, better power supply for PC computer case internal motherboard fans.

Widely Compatible
Support 4-pin and 3-pin fans cable, the 1 to 5 splitter 5 way fan power extension cable compatible with 4-pin and 3-pin PC case motherboard fans.

Plug-n-Play,Easy to plug; 5 way 4-pin male connector jack fan hub cable.

The extension cable offers greater flexibility between motherboard and CPU cooling fans.

Product description:

Brand: JMT

Colour: Black

Size: 70x20mm

Weight: 60g

Features:

Applicable: Suitable for 12V motherboard 3pin/4pin fan. (3pwm fan can also be used, but plugged in is running at full speed, because 3pin fan has no pwm speed control function)

The power supply is connected to the SATA interface. Add 5 capacitors.

Expand the 5-pin fan 4-pin connector to solve the problem of insufficient motherboard interface and centralized processing of fan wires.

The pwm interface is connected to the motherboard cpu fan interface, the red is the cpu fan dedicated interface, and the black interface is the pwm conventional fan interface.

The power supply can be directly powered by the power supply, which can reduce the load pressure on the main board. The temperature control line pwm is separately connected from the main board, and the power supply temperature control is correct.

The hub pcb board has a 3M backing on the back for easy adhesion to flat areas.

This product is a hub. The function is to expand the four-pin port of the motherboard to multiple ports. If your fan is a 3-pin fan, you can use it, but you can’t adjust the speed of pwm. Because this is a hub, not a governor.

Note: The color of the capacitor is black.

The product contains:

1 x small 4P interface hub

1 x 40cm cable

CPF04 is designed for enthusiasts with need for controlling numerous system fans.It is capable of expanding one motherboard PWM fan header to support up to eight fans. Powered directly by SATA cable from the computer power supply and filtered through a built-in 2200μF capacitor, the CPF04 can provide clean, stable voltage to any fan for optimal performance. Equipped with speed detection sensors for accurately controlling eight PWM fans simultaneously, it is an excellent solution for system fan expansion.

Feature:
Name: 4Pin 1 to 3 Ways PWM Fan Splitter Cable
Connector: 1x Mainboard 4Pin Female Socket
3x Fan 4Pin Male Plug
(4Pin: Power supply, speed control, speed detection, 3Pin: Power supply, speed control)
Length: 27cm/10.5″
Cable: 1007 24AWG, high density black sleeved cable
Insulation Material: PVC
Conductor: 11×0.12TS
Conductor Material: Tinned copper
Wire Diameter: OD1.4MM
Rated Temperature: 80 Degree
Color: Black
Function: Make the computer fan share an interface to realize power supply and PWM speed control, lengthen and extend the motherboard 4pin interface.

4Pin male splitter wire connection:
4Pin: Blue, Yellow, Red, Black
3Pin: Blue, Red, Black

Package Include:
1pcs 4Pin 1 to 3 Ways PWM Fan Splitter Cable

Features:
The wires are 26.5 cm, sleeved in red braiding with one 4 pin male to one Master 4 pin and Slave 4 pin female(Note: Slave 4 pin connector only has 3 needle,
In order to avoid the signal speed at the same time the conflict, Slave 4-pin fan misses one needle, does NOT have temperature control function(PWM))

Increase airflow:
The fan splitter cable provide an additional fan to increase airflow in your computer case, reduce the accumulation of heat within the chassis.

Package included: 2 x fan splitter cables

Feature:
Type: 4Pin IDE Molex 1 to 10 way cooling fan splitter hub
Color: Black
Material: Plastic + Metal
Size: 75x48mm/2.95¡Á1.89in (Approx.)
Power Supply Interface: 4Pin IDE Molex
Output Interface: 10 way fan 12V 4pin interface port, support simultaneous starting of 10 channel 4-Pin fans, solving the problem of shortage of motherboard. The orange interface is the dedicated interface for CPU fan, and the other black interfaces are conventional PWM fan interface.
PWM Interface: For connecting to CPU FAN interface, which support PWM function, on motherboard with connection cable.
Function: Support PWM function fan automatic speed regulation.
Installation: With EVA double-sided adhesive on the back, you can fix the hub in the chassis.
Application: Widely used for PC computer water cooling system.

Conditions to Achieve PWM Temperature Control:
1. The fan is a 4-pin PWM fan, which is very important. Some motherboard 4-pin interfaces are not a real PWM fan jack, they are adjusted by the voltage. Such motherboards can not make PWM control fans.
2. Connect the motherboard 4-pin fan interface, BIOS starts the PWM function.

Package Content:
1pcs 4Pin IDE Molex 1 to 10 way cooling fan splitter hub
1pcs 4-Pin PWM Cable

Features:
Capable of expanding one motherboard PWM fan header to support up to five fans.
Support PWM function, speed control, satisfy your control needs.
Compatible with 3-pin / 4-pin fans  (Due to 3 pins no PWM controller, 3-pin fans would run in full speed.)
Support cable management.
Comes with self-stick for easy installation and options to hide the PCB itself.
Since only one RPM signal can be read by one motherboard connector, only CPU Fan channel of the PWM splitter carries an RPM signal; Thus the motherboard will only read the RPM signal of the PWM device that is connected to channel 1 of the splitter.
Kindly Remind:
– Only the fan on CPU Fan channel is used for monitoring.
– All connected fans are following the same PWM signa, speed control is the same for all fans when use fan controller software like AI stuite/Xspert FAN and EASY TUNE, etc.
– PWM capable connectors must necessarily be 4-pin, but not all 4-pin motherboard connectors implement or enable the PWM signal modulation by default.
– Please carefully consult your motherboard documentation in this respect.
– This is only a fan hub, NOT fan speed controller.
– Only 4-pin PWM fans speed can be adjusted by fan controller software.
– 3-pin fan would run in full speed, can not be adjusted when connect.
Specifications:
Item Type: 5-Port Fan Hub
Material: Nylon + Plastic + Metal
Connector A: 1 – TX4 4-pin Female
Connector B: 1 – TX4 4-pin Male for CPU fan (including Detect tach pin);4/5 – TX4 4-pin Male for case fan
Package includes:
1 X 1 To 5 or 1 TO 4 4-Pin Molex TX4 PWM CPU Cooling Fan Splitter Adapter Cable (No retail package)

Features:

100% brand new and high quality.

Easy to install

Support chassis wiring

Support multi-channel PWM fan

Compatible with 3PIN, 4PIN fans

With adhesive backing, you can secure the hub to the chassis

Specifications:

Color: Shown as pictures

Size:30mm (Approx.)

Quantity: 2 pcs

Note:

1.Transition: 1cm=10mm=0.39inch

2.Please allow 0-1cm error due to manual measurement. pls make sure you do not mind before you bid.

3.Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!

Package includes: (No retail package)

1 X  Fans extension cable

Conclusion

By our suggestions above, we hope that you can found chasis cooling fan power cable hub splitter adapter for you.Please don’t forget to share your experience by comment in this post. Thank you!
